PERKO Inc. - Catalog - Underwater Hardware - Lightweight Intake Water Strainer [0443]

Figure No: 0443 - Legacy Product

Category: Underwater Hardware

Lightweight Intake Water Strainer [Fig. No. 0443]

Note: Selected figure numbers of this product are a part of our Perko Legacy program.

Perko Legacy products are no longer in regular production. Please contact our sales department for availability.

Please check the Ordering Information below. This icon ( ) denotes a Legacy product.

Product Description

Perko's lightest water strainer, the versatile 0443 is constructed from cast bronze with a clear polymer body. Designed for easy installation, it features mounting lugs cast into both sides for universal fitting.

Hinged lugs in the cover permit simple removal for cleaning of the strainer basket. Made of 316 stainless steel, the basket minimizes electrolysis. With screen holes 0.079" in diameter, the Lightweight Intake Water Strainer provides 47% open area, which is among the highest in the industry for cylindrical models.

A drain plug in the bottom casting simplifies sediment removal and draining for winterizing. The reliable 0443 Lightweight Intake Water Strainer shares many replacement parts with other Perko strainers.

Cast Bronze with Clear Polymer Body
Our Lightest Weight Strainer
Many Replacement Parts in Common with Other PERKO Strainers (Fig. 0493)

Technical Information

Depth: 8-1/2"

Ordering Information

Pipe Size Inches	Standard Pkg. - 1 Pc.	Height Overall Inches	Width Overall Inches	Dimensions Cylinder Inches O.D. x L	Open Area Dimensions Basket Inches	Each Side Open Area Ratio	Ship Wt. Carton Lbs. Std. Pkg.	Spare Gasket Kit* Dealer Pkg. - 5 Kts. 1 Kit per Bag
1/2	0443004PLB	6-1/4	4-1/2	3-1/2 x 4-1/4	1-13/16 x 4-3/8	30:1	3.9	0443DP599R
3/4	0443005PLB	8-5/8	4-1/2	3-1/2 x 6-5/8	1-13/16 x 6-1/4	25:1	4.0	0443DP599R
1	0443006PLB	8-3/4	5-1/2	4-1/2 x 6	2-5/8 x 5-7/8	20:1	6.7	0443DP799R
1-1/4	0443007PLB	9-5/16	5-1/2	4-1/2 x 6-9/16	2-5/8 x 6-1/4	13:1	6.5	0443DP799R
1-1/2	0443008PLB ( Legacy)	11-3/4	7-1/4	6 x 8-5/8	3-5/16 x 8-7/16	17:1	11.1	0443DP999R

Instructions & Resources

Fig. 0443 Installation Instructions

Fig. 0443 Spare Parts Diagram

View Fig. 0443 in our Print Catalog

Spare Parts

For Spare Part No. Insert a Spare Part Code Listed Below in Place of the “PLB” in the Strainer’s Catalog Number (i.e., 059400699A, Top Casting for 1-1/2” (#8) Strainer)

Description	Spare Part Code	Sample Part Number	Package
Top Casting	99A	049300499A	Boxed
Transparent Cylinder Body	99C	044300499C	Boxed
Basket Strainer	99D	049300499D	Boxed
Cover with Gasket	99E	049300499E	Boxed
Hinged Bolt for Cover with Pin, Nut and Washer	99L	0493DP599L	Bag
Rubber Gasket Kit Consists of : 1 Cover Gaskets & 1 Body Gasket	99R*	0443DP599R	Bag
Nuts and Washers Consists of : 4 Each for 0443 Series	99F	0443DP499F	Bag
